Socomec
Socomec SLB Load Break Switch kit, w/ External Handle, 4P 400A
Item No. SLB4004P
Product Range: SLB
Component Type (ETIM Class)
Switch disconnector
Electrical
Max. rated operation voltage Ue AC12000 V
Rated permanent current at AC-21, 400 V400 A
Rated permanent current Iu400 A
Number of poles4
Rated operation power at AC-23, 400 V220 kW
Rated operation current Ie at AC-23a, 400 V400 A
Rated operation current Ie at AC-23a, 500 V315 A
Rated operation current Ie at AC-23a, 690 V160 A
Rated operation current Ie at DC-23a, 220 V400 A
Construction
Degree of protection (IP), front sideIP65
Version as main switchYes
Version as reversing switchNo
Number of switches1
Suitable for floor mountingNo
Suitable for front mounting 4-holeNo
Suitable for front mounting centreNo
Suitable for distribution board installationYes
Suitable for intermediate mountingNo
Mechanical
Padlock lockingYes
Dimensions
Height235 mm
Width270 mm
Depth110 mm
Conductor cross section solid (solid, stranded)185-240 mm²
Connectable conductor cross section185240 mm²
