NHP
NHP DIN-T Contactors 25A 4 Normally Closed Contacts 240V AC DC Coil
Item No. DTC2504240D
Product Range: DIN Contactors
Component Type (ETIM Class)
Power contactor, AC switching
Electrical
Number of normally open contacts as main contact0
Number of normally closed contacts as main contact4
Rated operation current Ie at AC-3, 400 V9 A
Rated operation power at AC-3, 400 V4 kW
Rated operation current Ie at AC-1, 400 V25 A
Max. rated operation voltage Ue AC500 V
Voltage type for actuatingAC/DC
Rated control supply voltage Us at AC 50HZ230-240 V
Control supply voltage Us at DC240 V
Construction
IP ratingIP20
Mounting methodDIN rail mounting
Dimensions
Height85 mm
Width36 mm
Depth58 mm
Weight0.23 kg
