Allen-Bradley
Allen-Bradley PowerFlex 755 VSD 400V IP20 ND 3.5A 1.5kW or HD 2.1A 0.75kW Frame 1
Item No. 20G11RC3P5JA0NNNNN
Product Range: PowerFlex 755
Component Type (ETIM Class)
Frequency converter =< 1 kV
Electrical
Number of phases input3
Nominal input voltage400 V
Nominal output power AC1.5 kW
Nominal output current I2N3.5 A
kW rating, normal duty1.5 kW
kW rating, heavy duty0.75 kW
Dynamic braking transistorYes
Control characteristicPID
EMC-versionYes
Communication
Integrated motion functionNo
Construction
Suitable for safety functionsYes
Contains keypadNo
Frame size1
Degree of protection (IP)IP20
Dimensions
Height400 mm
Width190 mm
Depth211.1 mm
Weight6 kg
Environment
Operating temperature-20-60 °C
Storage temperature-40-70 °C
